Sony X90L: Powerful Processor for a Realistic and Immersive TV Experience

Now featured in ListenUp's Great Gear of the Year in Hi-Fi and Home Theater for 2024! Watch it here.

The Sony X90L is a 4K HDR Google TV that uses the Cognitive Processor XR™ to deliver realistic picture quality. With Full Array LED backlighting and XR Contrast Booster™, the X90L offers deep blacks and impressive brightness. XR Triluminos Pro™ brings you billions of vibrant colors.

Google TV and BRAVIA CORE™

The X90L comes with Google TV, which allows you to access over 700,000 movies and TV episodes. You can also use BRAVIA CORE™ to stream the latest Sony Pictures Entertainment titles and a large selection of IMAX® Enhanced movies.

Gaming Features

The X90L supports 4K/120, VRR, and ALLM for a smooth gaming experience. It also has exclusive features for the PlayStation® 5 console, such as Auto HDR Tone Mapping and Auto Genre Picture Mode.

Enhanced Viewing with Dolby Vision® and IMAX®

Dolby Vision® and IMAX® Enhanced bring scenes to life with vivid colors and powerful sound. The X90L also supports Netflix Adaptive Calibrated Mode, which adjusts brightness based on your room's lighting conditions.

Immersive Audio Experience

Acoustic Multi-Audio™, Dolby Atmos® support, and 3D Surround Upscaling create a realistic audio experience. You can also pair the X90L with Sony soundbars for an even better audio experience.

Other Features

XR Clear Image and XR 4K Upscaling improve the quality of HD and digital content.
XR Motion Clarity™ reduces blur in fast-moving scenes.
Hands-free voice control with Google Assistant
Supports popular streaming apps, including Netflix, Prime Video, and Disney+
Family-friendly features, such as Kids Profile and parental controls
Works with AirPlay
Sleek design with a two-way multi-position stand
Compatible with BRAVIA CAM for video chat and other features

Overall, the Sony X90L is a great option for anyone looking for a high-quality TV with a powerful processor, realistic picture quality, and a wide range of features.

Sony BRAVIA X90L Specifications

Audio Specs:

Channel: 2ch
Audio Power Output: 10W + 10W + 5W + 5W
Speaker Position: Down Firing + Side Back
Bass/Treble/Balance: Balance
Speaker Type: Acoustic Multi-Audio
Speaker Configuration: Full Range (Bass Reflex) x 2, Tweeter x 2
Digital Audio Out (Optical) Format:

Two Channel Linear PCM: 48kHz 16bits
Dolby Audio
DTS (Pass-through mode only)

Customizing Capability:

RS-232C Control: Yes

Design Features:

Stand Color: Dark Silver
Bezel Design: Seamless Edge
Frame Color: Dark Silver
Stand Design: Aluminum Slim Wedged Stand
Stand Position: 2-way Position (Standard Position/Soundbar Position)

Display Features:

Display Type: Full Array LED
Backlight Dimming Type: Local Dimming

Display Specs:

Display Resolution (H x V, Pixels): 3840 x 2160
Viewing Angle (Right/Left): 178(89/89) degrees
Viewing Angle (Up/Down): 178(89/89) degrees
Display Resolution: QFHD
Aspect Ratio: 16:9
Backlight Type: Direct (Full Array LED)

Energy Saving & Efficiency:

Dynamic Backlight Control: Yes
Power Saving Mode/Back Light Off Mode: Yes
SORPLAS: Yes
ECO FRIENDLY: Yes

Network Features:

APPLE AIRPLAY: Yes
APPLE HOMEKIT: Yes
Home Network Feature: Home Network Client, Home Network Renderer
Wi-Fi Direct: Yes
Wi-Fi Certified: Yes
Screen Mirroring (Miracast™): Yes (only for B2B purpose)
Video & TV SideView (iOS/Android): Yes
Related Info: Yes (US, Canada, Mexico)
Wi-Fi Standard: a/b/g/n/ac
Wi-Fi Frequency: 2.4GHz/5GHz (for Wi-Fi Direct: 2.4GHz Only)
Codec for Home Network:

MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)

Wireless LAN: Integrated
Control Menu: Yes
ECO Dashboard: Yes

Optional Accessories:

Wallmount Bracket: SU-WL855 (Refer to Country/Area Handling Chart)
Camera Unit (Option): CMU-BC1

Regulation and Standard Compliance:

VESA® Hole Spacing Compatible: Yes

Sensing Features:

Sensor: Light

Supplied Accessories:

Operating Instructions: EN, FR, ES
Batteries: LR03
AC Power Cord Spec: Bundle (C7L) (US) (2pin) (flat blades)
Quick Setup Guide / Supplement CUE (GA): EN, FR, ES, PT
Table Top Stand: Separate (Assembly required)
Voice Remote Control (Supply): RMF-TX810U

TV System:

TV System (Analog): M
Tuner Channel Coverage (Analog): VHF: 2-13/UHF: 14-69/CATV: 1-135
TV System (Digital Terrestrial): ATSC/ATSC3.0 (NEXTGEN TV) depending on your country/area selection
Tuner Channel Coverage (Digital Terrestrial): VHF: 2-13/UHF: 14-69(2-13/14-36 for ATSC3.0)
TV System (Digital Cable): Clear QAM
Tuner Channel Coverage (Digital Cable): CATV: 1-135
Number of Tuners (Terrestrial/Cable): 1 (Digital/Analog)
Color Space: sRGB/BT709, BT2020, AdobeRGB, DCI
Operating System: Google TV
On-board Storage (GB): 32GB

TV System:

Color System: NTSC

Audio Features:

Acoustic Auto Calibration: Room & User Position Compensation
Clear Phase: Yes
S-Master: S-Master Digital Amplifier
Auto Surround: Yes
DTS Audio Format Support: DTS Digital Surround
Sound Modes: Standard, Dialog, Cinema, Music, Sports, Dolby Audio
Simulated Surround Sound: S-Force Front Surround
Dolby Audio Format Support: Dolby Audio, Dolby Atmos
Voice Zoom: Voice Zoom 2
HDMI Audio Return Channel(ARC): Yes (eARC/ARC)
Advanced Auto Volume: Yes
Auto Mute (on no signal): Yes
HDMI Input Audio Format:

5.1 Channel Linear PCM: 32/44.1/48/88.2/96/176.4/192kHz 16/20/24bits
Dolby Audio, Dolby Atmos, DTS

ARC Output Format:

Two Channel Linear PCM: 48kHz 16bits
Dolby Audio, Dolby Atmos, DTS (Pass through mode only)

Acoustic Center Sync: Yes (S-CENTER SPEAKER IN)
Ready for 360 Spatial Sound Personalizer: Yes (with WLA-NS7)
Vertical Surround Engine: Vertical Surround Engine
Speaker Type-2: Sound Positioning Tweeter, X-Balanced Speaker

Inputs and Outputs:

HDMI Signal:

4096x2160p(24,60Hz)
3840x2160p(24,30,60,120Hz)*2
1080p(24,30,60,120Hz)
1080i(60Hz)
720p(24,30,60Hz)
480p

HDCP: HDCP2.3(for HDMI1/2/3/4)
Bluetooth Profile Support: Version 4.2, HID/HOGP/SPP/A2DP/AVRCP
4K 60P High-Quality Formats: HDMI IN1, IN2 ports for 4K(up to 18Gbps) signal, HDMI IN3, IN4 port for 4K(up to 48Gbps) signal
AC Power Input: C8 INLET(REAR)
RF (Terrestrial/Cable) Connection Input(s): 1(Side)
Composite Video Input(s): Hybrid w/S-Center Speaker Input x1(Side, Mini Jack)
HDMI Inputs Total: 4(4Side)
Analog Audio Input(s) (Total): 1(Side Analog Conversion)
Digital Audio Output(s): 1(Side)
USB Ports: 2 (Side)
Ethernet Inputs: 1(Side)
RS-232C Input(s): 1(Side)
HDMI PC Input Format:

640x480(31.5kHz,60Hz)
800x600(37.9kHz,60Hz)
1024x768(48.4kHz,60Hz)
1280x1024(64.0kHz,60Hz)
1152x864(67.5kHz,75Hz)
1600x900(55.9kHz,60Hz)
1680x1050(65.3kHz,60Hz)
1920x1080(67.5kHz,60Hz)
3840x2160p(30Hz)
3840x2160p(60Hz, 8bits)

Power:

Power Requirements (Voltage): AC 120V for UL cUL AC 110-240V for other
Power Requirements (Frequency): 60Hz for UL cUL 50/60Hz for other
Rated Power Consumption: 265 W
Power Consumption (in Standby): 0.5 W

Video Features:

Object-based Super Resolution: XR Super Resolution
Precision Color Mapping: Yes
Face Area Detection: Yes
Picture Modes:

Vivid, Standard, Cinema, IMAX Enhanced, Game, Graphics, Photo, Custom, Dolby Vision (Vivid/Bright/Dark), Netflix Calibrated, BRAVIA CORE Calibrated

Auto Wide: Yes
Wide Mode: Wide Zoom/Normal/Full/Zoom, Normal/Full1/Full2 for PC
4:3 Default: Yes
Video Processing: XR 4K Upscaling
Motion Enhancer: XR Motion Clarity
24p True Cinema: Yes
Live Colour™ Technology: Yes
PhotoTV HD / BRAVIA 照片秀 for China: Yes
CineMotion/Film Mode/Cinema Drive: Yes
4K Processor: Cognitive Processor XR
HDR (High Dynamic Range) Compatibility: Yes(HDR10,HLG,Dolby Vision)
Panel Refresh Rate (Native Hertz): 120Hz
Dual Database Processing: Yes
Dynamic Contrast Enhancer: Yes
Peak Luminance: XR Contrast Booster 10
TRILUMINOS: XR Triluminos Pro
HDR Remaster: XR HDR remaster
Smoothing: XR Smoothing
Features for PlayStation®5 Auto HDR Tone Mapping: Yes
Features for PlayStation®5 Auto Genre Picture Mode: Yes
XR Clear Image: Yes

Convenience Features:

Features Specified in HDMI2.1: 4K120/eARC/VRR/ALLM
Electronic Program Guide (EPG): Yes
USB Playback Codecs:

MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)

Screen Reader: Yes
Audio Description: Yes
Text Magnification: Yes
Accessibility Shortcut: Yes
Switch Access: Yes
Auto Picture Mode: Yes
Text Input Language: ENG / FRA / GER / HEB / ITA / RUS / SPA / VIE / JPN
Chromecast Built-in: Yes
Voice Search: Yes
Application Store: Yes (Google Play Store)
i-Manual: Yes
Parental Control: Yes
Channel Block (with Password): Analog & Digital
Show/Hide Channels: Yes(Digital & Analog)
On Screen Clock: Yes
Sleep Timer: Yes
On/Off Timer: Yes
USB Drive Format Support: Yes (Supported File System: FAT16/FAT32/exFAT/NTFS)
Display Language:

AFR, AMH, ARA, ASM, AZE, BEL, BUL, BEN, BOS, CAT, CZE, DAN, DEU, GRE, ENG, SPA, EST, BAQ, PER, FIN, FRA, GLG, GUJ, HIN, HRV, HUN, IND, ISL, ITA, HEB, JPN, KAZ, KAN, KOR, KIR, LAO, LIT, LAV, MAC, MAL, MON, MAR, MAY, BUR, NOB, NEP, NLD, ORI, PAN, POL, POR, RUM, RUS, SOL, SLV, ALB, SRP, SWE, SWA, TAM, TEL, THA, TGL, TUR, UKR, URD, UZB, VIE, zh_CN, zh_HK, zh_TW, ZUL

Auto Shut-off: Yes
UVC/UAC Support: Yes
TALKBACK: Yes
Variable Refresh Rate (VRR): Yes (for HDMI3/4)
Auto Low Latency Mode (ALLM): Yes (for HDMI3/4)
BUILT-IN MIC SWITCH: Yes(Center)
Built-in Mic: Yes

BRAVIA SYNC (INCLUDING HDMI-CEC): Yes

General Features:

Auto Calibration with CalMAN: Yes
NETFLIX CALIBRATED MODE: Yes
IMAX Certified Model: Yes
Closed Captions (Analog): Closed Caption
Closed Captions (Digital): Closed Caption
Demo Mode: Yes (e-POP only)
SMART TV: Google TV
BRAVIA CORE Calibrated Mode: Yes
BRAVIA CORE: 5 credits / 12 months
