KEF Ci130.2CR Ci-C Series In-Ceiling Speaker

Enhance your home audio experience with the KEF Ci130.2CR Ci-C Series In-Ceiling Speaker, featuring cutting-edge technology and superior sound dispersion. Ideal for flush mount installations, this speaker delivers high-performance audio with seamless integration into any space.

Key Features:

• KEF Uni-Q® Technology: Patented driver array places the tweeter in the acoustic center of the woofer, ensuring wide dispersion and consistent sound quality throughout the room.
• Tangerine Waveguide: Enhances high frequency dispersion for 140 degrees of coverage, delivering smooth and immersive sound.
• Weather Resistant: UV protected and constructed with durable materials, making it suitable for both indoor and outdoor use.
• IP64 Certified: Passed official IEC testing for resistance to splashing water, ensuring reliability in various environments.
• Ultra-Thin Bezel (UTB): Sleek design with barely visible bezels for a seamless aesthetic.
• Magnetic Grille: Securely attaches with a powerful magnetic circuit and can be painted to match any décor.
• Covered Crossover Circuit: Protects electrical components while adding structural rigidity to the speaker assembly.
• Universal Cut-Out: Compatible with all KEF 130mm in-ceiling speakers, simplifying installation and component selection.

Specifications:

• Nominal Impedance: 8 Ohms
• Sensitivity: 87dB (2.83V/1m)
• Frequency Response: 52Hz-20kHz (+/-6dB)
• Crossover Response: 2.5kHz
• Drive Units: LF - 130mm (5.25in.) Uni-Q, HF - 16mm (0.6in.) Aluminium dome tweeter
• Recommended Amplifier Power: 10-80W
• Product External Dimensions: Diameter - 193.4mm (7.61in.), Depth - 82.3mm (3.24in.)
• Cut-Out Dimensions: Diameter - 158mm (6.22in.)
• Mounting Thickness: Ceiling Thickness (Maximum) - 33mm (1.300in.), Ceiling Thickness (Minimum) - 6mm (0.240in.)
• Mounting Depth From Surface: 77.7mm (3.06in.)
• Optional Rough In Frame: RIF130R
• Optional Rear Enclosure: RNC130R
• Net Weight: 1.3kg (2.8lbs)

Upgrade your audio system with the KEF Ci130.2CR Ci-C Series In-Ceiling Speaker, designed to deliver exceptional sound performance and versatility in any setting.

KEF Ci130.2CR Downloads

KEF Ci130.2CR Manual
KEF Ci130.2CR Specification Sheet
KEF Ci130.2CR Cutout Template
KEF Ci Minimum Cabinet Volume Chart
KEF Architectural Brochure
KEF Architectural Selection And Setup Guide
KEF Architectural Accessory Reference Guide
KEF Architectural Speaker Group Specification Sheet
